UP TO 22 KW PROFESSIONAL AC WALL‑MOUNTED CHARGER
Small Footprint. Full Power.
A refined design that merges with its surroundings while saving space. The ideal wall‑mount solution, certified for indoor and outdoor applications. Up to 22 kW output for a full recharge in a matter of hours. Compatible with all AC plugs, built with heavy‑gauge metals and industrial‑grade components. Compact, elegant, reliable.
The ideal solution for overnight charging — and saving space. Discreet enough to disappear into any architectural context, robust enough to handle daily commercial use. The Q is QiOn's answer to smart, space‑efficient AC charging.
Product Specifications
Height (A):400 mm (15.6")
Width (B):150 mm (5.8")
Depth (C):250 mm (9.7")
Net Weight:8.5 kg (19 lb)
Cable Length:5–7.5 m (16.5–24.6 ft)
Voltage Output:AC Single Phase 220 V±10% / Three Phase 380 V±10%
Current Output:32 A / 50 A / 64 A / 80 A
Frequency:50/60 Hz
Power Output:7 / 11 / 22 kW
